Product Overview
Our custom half-slotted container (HSC) with die-cut partitions is engineered specifically for the safe transport of glass bottles — wine, spirits, olive oil, gourmet beverages, and pharmaceutical liquids. The HSC design features an open top with flaps on one face only, combined with precisely die-cut interlocking dividers that isolate each bottle and prevent glass-to-glass contact during transit. Manufactured from double-wall B/C flute corrugated board for superior crush resistance, each container is assembled with industrial hot-melt adhesive for structural integrity. Bincai’s 23 years of packaging expertise and ISO 9001-certified quality system ensure every shipper meets ISTA performance standards.
Design Features
- Half-Slotted Container (HSC) Design: Open-top construction with flaps on one face for easy loading and unloading
- Die-Cut Interlocking Partitions: Precision-cut dividers create individual cells for each bottle — no glass-to-glass contact
- Double-Wall B/C Flute: Combined B-flute (3mm) and C-flute (4mm) for maximum stacking strength and puncture resistance
- Kraft or White Top Liner: Natural kraft for industrial use or white-coated top liner for branded presentation
- Hot Melt Adhesive Assembly: Industrial-grade hot melt bonding for structural rigidity during palletized transport
- Custom Cell Configuration: 2-bottle, 3-bottle, 6-bottle, and 12-bottle partition layouts available
- Flat-Pack Shipping: Ships flat to minimize freight volume; assembles on-site in seconds
Applications
- Wine and champagne bottle shipping for wineries and distributors
- Spirits and liquor bottle transport (whiskey, vodka, gin, rum)
- Olive oil and gourmet food bottle distribution
- Craft beer and cider bottle shipping
- Pharmaceutical and laboratory glass bottle logistics
- Cosmetic and fragrance bottle bulk transport
Customization Options
- Box dimensions tailored to exact bottle height, diameter, and count
- Board grades: single-wall C flute, double-wall B/C flute, or triple-wall for heavy bottles
- Liner options: natural kraft, white top, or clay-coated for custom printing
- Cell count: 2, 3, 4, 6, 8, or 12 bottle configurations
- Custom flexographic printing on exterior panels: 1–3 colors
- Perforated tear-strip for easy retail conversion
- Hand holes for ergonomic carrying
- Partition material: corrugated, chipboard, or molded pulp fiber
Production Specifications
|| Specification | Detail |
||—|—|
|| Board Grade | Double-Wall B/C Flute Corrugated — B-flute (3mm) + C-flute (4mm) for 7mm total thickness |
|| Box Style | Half-Slotted Container (HSC) — open top with flaps on one face for fast loading |
|| Partition Type | Die-Cut Interlocking Corrugated Dividers — precision-cut cells isolate each bottle |
|| Assembly | Industrial Hot Melt Adhesive — applied on automated gluer for structural integrity |
|| Exterior Printing | 1–3 Color Flexographic on kraft or white-top liner |
|| Press Lines | Heidelberg Speedmaster XL 7+1 UV × 2 / KBA Rapida 105 4-color × 3 / Automated Corrugator Line |
|| Factory | 18,000 sqm (10,000 + 8,000 smart factory) in Foshan, Guangdong |
|| Experience | 23 years (founded 2003) — serving 60+ countries worldwide |
|| Daily Output | 1.7M+ boxes across dual factories |
|| Certifications | ISO 9001:2015, FSC® Chain-of-Custody |
Quality Assurance
|| Checkpoint | Standard | Method |
|—|—|—|
|| Edge Crush Test (ECT) | ≥32 lb/in for B/C double-wall | Universal testing machine, 1:500 sampling |
|| Drop Test | 0.76m free-fall, 10 drops with weighted bottles | ISTA 1A; pass: no partition failure, no glass contact |
|| Box Compression | ≥600 lbs top-to-bottom | Compression tester, 1:200 sampling |
|| Partition Fit | ≤1mm lateral play per cell | Manual gauge test, 100% inline |
|| Adhesive Bond | Hot melt peel strength ≥4N/15mm | Tensile tester, 1:200 sampling |
|| Dimension Accuracy | ±2mm | Caliper measurement, first article + random |
|| FSC Chain-of-Custody | Full traceability | FSC-STD-40-004 v3-0 |
